Heat-sealing foil lamination Suitable for online lamination of glasswool, rockwool, mineral wool insulation. Thicker heat-sealable PE. No need applying extra adhesive. Good corrosion resistance.
Quantity
ProductDescription

Application

FKV-7501Foil: 7u / PE / Kraft: 50gsm / PE: 25u

Eco Grade heat-sealing foil facing.

No scrim inside.

No need applying extra adhesive.

Good corrosion resistance.

FSKV-7150AFoil: 7u / PE / 3-way Scrim 8 x12 ends / Kraft: 50gsm / PE: 25u

Utility Grade, 3-way scrim heat-sealing FSK facing.

Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation.

No need applying extra adhesive.

Good corrosion resistance.

FSKV-7160AFoil: 7u / PE / 3-way Scrim 8 x12 ends / Kraft: 50gsm / PE: 25u

Commercial Grade, 3-way scrim heat-sealing FSK facing.

Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation.

Thicker Kraft.

No need applying extra adhesive.

Good corrosion resistance.

FSKV-7150BFoil: 7u / 2-way Scrim 12.5x12.5mm / PE / Kraft: 50gsm / PE: 25u

Utility Grade, 2-way scrim heat-sealing FSK facing.

Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation.

No need applying extra adhesive.

Good corrosion resistance.

1. Products List

Product

Description

Application

FSKV-7160B

Foil: 7u / 2-way Scrim 12.5x12.5mm / PE / Kraft: 50gsm / PE: 25u

Commercial Grade, 2-way scrim heat-sealing FSK facing. Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation. Thicker Kraft. No need applying extra adhesive. Good corrosion resistance.

FKSV-7502A

Foil: 7u / Heat resistant glue /Kraft: 50gsm / 3-way Scrim 8 x12 ends / PE: 25u

Utility Grade, 3-way scrim heat-sealing FSK facing. Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation. No need applying extra adhesive. Good corrosion resistance.

FKSV-7602A

Foil: 7u / Heat resistant glue /Kraft: 60gsm / 3-way Scrim 8 x12 ends / PE: 25u

Commercial Grade, 3-way scrim heat-sealing FSK facing. Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation. No need applying extra adhesive. Good corrosion resistance.

FKSV-7501B

Foil: 7u / Heat resistant glue/Kraft: 50gsm/ 2-way Scrim 12.5x12.5mm / PE: 25u

Utility Grade, 2-way scrim heat-sealing FSK facing. Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation. No need applying extra adhesive. Good corrosion resistance.

FKSV-7601B

Foil: 7u / Heat resistant glue/Kraft: 60gsm/ 2-way Scrim 12.5x12.5mm / PE: 25u

Commercial Grade, 2-way scrim heat-sealing FSK facing. Suitable for in-line lamination of glasswool, rockwool, mineral wool insulation. Thicker Kraft. No need applying extra adhesive. Good corrosion resistance.

FSV-1808B

Foil: 18u / 2-way Scrim: 5x5mm / Polyethylene: 25u

Premium Grade heat-sealing foil-scrim facing. Suitable for in-line lamination with glasswool, rockwoo, mineral wool., and foam insulation. Thicker foil and very closer 2-way scrim.

2. Typical Physical Properties

Product

Basic Weight

(g/m2)

WVTR

ng/N.s

Tensile MD

(N/25mm)

Tensile XD

(N/25mm)

Bursting Strength (N)

Fire Rating

FKV-7501

95

1.15

105

55

25

---

FSKV-71501A

102

1.15

125

65

30

---

FSKV-71601A

112

1.15

140

75

33

---

FSKV-71501B

102

1.15

125

70

30

---

FSKV-71601B

112

1.15

140

80

33

---

FKSV-7502A

100

1.15

135

50

30

---

FKSV-7602A

113

1.15

140

76

38

---

FKSV-7501B

100

1.15

116

75

35

---

FKSV-7601B

110

1.15

132

80

38

---

FSV-1808B

80

1.15

75

70

35

Class O

IMPORTANT NOTE:

1. The data above are typical values only, and should not be used for specifications purpose.

2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Log Roll: ±0.3m, Jumbo Roll ±0.5%.

3. The products should be stored at room temperature, kept away from wet and heat source.

4. The users should take test and do trial-application on the above products before coming into application so as to witness and ensure suitability for their special purpose and technique.
