We have full line of aluglass products with and without PE coating backed with different thickness of foils, such as 7 micron, 12 micron, 15 micron, 18 micron, 25 microns, 30 microns etc. For fiberglass clothes, the grammage ranges from 75 gsm, 80 gsm, 90 gsm, 100 gsm, to 1000 gsm etc. For high end requirements, alki-free fiberglass cloth 7628 & 2116 are also widely used for lamination with foils.
1．Product List
Perfect lamination's aluglass foil facings are widely used to protect the surface of insulation products, such as glass wool, rock wool, rubber foam, PE foam, PIR, PUR foam etc. with excellent fire proof performance and can pass the ASTM E84, BS476 test.We have full line of aluglass products with and without PE coating backed with different thickness of foils, such as 7 micron, 12 micron, 15 micron, 18 micron, 25 microns, 30 microns etc. For fiberglass clothes, the grammage ranges from 75 gsm, 80 gsm, 90 gsm, 100 gsm, to 1000 gsm etc. For high end requirements, alki-free fiberglass cloth 7628 & 2116 are also widely used for lamination with foils.
Product | Description | Application |
FG-701 | Foil: 7u / PE / Glass Cloth: 12 x 12 Mesh, 110gsm | Utility Grade Alum.-Glass Cloth Facing. High tensile strength and tear-resistance. Good as a vapor barrier of duct wrap, duct board and pipe insulation. |
FG-R701 | Foil: 7u / FR Glue / Glass Cloth: 12 x 12 Mesh, 110gsm | Utility Grade F/R Alum.-Glass Cloth Facing. High tensile strength and tear-resistance. Good as a vapor barrier of duct wrap, duct board and pipe insulation. |
FG-R1801 | Foil:18u / FR Glue / Glass Cloth: 8 x 8 Mesh, 95gsm | High-Grade F/R Alum.-Glass Cloth Facing. Thick foil, UL 723 approval. Excellent for industrial and vessel engine room’s thermal Insulation. |
2．Typical Physical Properties
Foil-Kraft Facing / Foil-Scrim-Kraft Facing | ||||||
Product | Basic Weight (g/m2) | WVTR ng/N.s | Tensile MD (N/25mm) | Tensile XD (N/25mm) | Bursting Strength (N) | Fire Rating |
FG-701 | 160 | 5.75 | 310 | 190 | 125 | --- |
FG-R701 | 130 | 5.75 | 260 | 180 | 125 | Class O |
FG-R1801 | 150 | 5.75 | 260 | 180 | 125 | Class O |
IMPORTANT NOTE:
1. The data above are typical values only, and should not be used for specifications purpose.
2. Tolerance: Weight and Thickness: ±10%; Width: ±3mm; Length: Log Roll: ±0.3m, Jumbo Roll ±0.5%.
3. The products should be stored at room temperature, kept away from wet and heat source.
4. The users should take test and do trial-application on the above products before coming into application so as to witness and ensure suitability for their special purpose and technique.
* Please kindly contact with sales staff confirm the specific specifications.
